Some people use term bagging and boosting, some use parallel and sequential ensembles. I have written a post on AdaBoost previously. So we are familiar with boosting idea.

In AdaBoost we had a formula for generating labels (label/sample weight in loss function to be precise) for next iteration. In gradient boosting we fit gradient of loss function with respect to predictions.

Prof Balaraman notes

• Most of this post contains info from [0]. However Prof. Balaraman offers intuitive perspective in one of his lectures. [3]
• My handwritten note on that is available at [2]
• We can write decision tree as equation where regions and value in the region are parameters.
• Two steps of gradient boosting
  1. Fit gradient of loss function using regression trees (least square loss)
  2. Compute values in region using loss defined for application (ndcg for ranking, log-loss for classifier anything)
• Whatever is application loss, we fit regression tree using least square
• Parametric gradient descent can be seen as series of summation starting from initial guess.
• Related paper [4]

Basis Functions

• Basis functions
  • If we want to fit non linear curve with simple linear regression, we will create polynomial features
  • It is not limited to regression though
• Adaptive Basis function
  • Instead of we defining above functions, we learn them
  • This can be framed as optimisation problem and can be solved by gradient descent/newton’s method for some hypothesis space
• How to include Tree’s in base hypothesis space
  • Something which we can not differentiate
  • Even if we fix parameters to split on output is still not continuous
  • So it is difficult

FSAM

• FSAM
  • Forward Stage-wise Additive Modelling
  • AdaBoost is example of this, another example is L2 boosting
  • We can say weak function is step direction and coefficient is step size

• L2 Boosting also example of FSAM
  • We are fitting residual
  • To prevent overfitting we can reduce step size
  • If v*h(x) is also in H, we can remove v. (closed under rescaling)
  • h(x) can be decision stump we can keep going as long as residuals exist (It will certainly overfit after few iterations)

• Adaboost
  • It works for classification problem
  • When the loss function in FSAM is exponential loss of margin, it reduces adaboost
  • margin = y*f(x)
    • We had encountered that in SVM

• Disadvantages of AdaBoost
  • Gives too much penalty for negative margin, look at the curve of exponential above
  • Mislabel training data
  • Sometimes there is noise in world
  • Does not work when there is high baye’s error
  • Also it seems AdaBoost formulation is very much tied to classification
    • We probably needs to tweak it to apply it to ranking problem
    • But gradient boosting can be applied to any problem (loss function)
      • Because Tree is alway using L2 loss

Functional Gradient Descent

• Gradient is pseudo residuals
  • For L2 loss it is actually residuals (difference between y and f)
  • Examples where residuals are not just difference between y and f
    • logistic loss
    • ranking using ndcg
• We fit this gradient(pseudo-residuals) with weak function
  • Regression Tree is most common
  • We find closest approximation to gradient step in base hypothesis space (which is functional space)
  • Here we minimize square loss (regression problem)
• Earlier tree used to be just stumps
  • That is num of leaf node = 2
  • Now a days xgboost/light gbm takes upto 8/16 leaf nodes as well
• Note that while calculating gradient the hypothesis function is not involved anywhere
• How do we calculate gradient over function space
  • In close form expression it might look complicated
  • From numerical computation perspective we need gradient at just one point (of dimension training data size)
  • This is just like taking gradient of weights in linear regression
    • Here size of gradient vector would be number of training examples
  • In most of the method we take gradient of parameters, here we are taking gradient of predictions
• What should be step size
  • Line search
  • Regularisation parameter (similar to what we use for any gradient based optimisation)
    • This is more common

Reference

[0] https://www.youtube.com/watch?v=fz1H03ZKvLM

[1] https://davidrosenberg.github.io/mlcourse/Archive/2016/Lectures/8b.gradient-boosting.pdf

[2] https://github.com/arcarchit/datastories/blob/master/notes/gradient_boost_iitm.pdf

[3] https://www.youtube.com/watch?v=FJ-MA0EfJ9k

[4] https://statweb.stanford.edu/~jhf/ftp/trebst.pdf
